PCB Layout Design
PCB Layout Services
Our PCB designers, most with over 20 years of experience, are skilled in both
analog and digital design, as well as mixed signal technologies. Our portfolio
of interfaces includes PCIe Gen 5, DDR5, 5G, and includes a multitude of RF
and Mobile design work.
Our DFX team engages with our customers early in the design phase,
addressing any design issues, and implements design strategies using a
systematic approach. Our PCB yields are some of the highest in the industry
due to our rigorous processes, and our customers benefit with faster design
cycles, and fewer design iterations.
Our best-in-class design team provides
- Stack up modeling
- Footprint library development
- BOM verification
- Mechanical outline control
- 3D model development of electronic components
- 3D assembly and interference analysis
- Multilayer PCB layout (up to 34 layers)
- Constraint management
- Gerber/Deliverable package for fabrication/assembly
- Design for manufacturing
- Design for assembly
- Design for testing
- Panel/Array designing
- CAM editing
Our Strengths in PCB Layout Services and DFX
20+ years of average experience per PCB designer
Experienced in advanced technologies / high-speed interfaces
Combination of EEs and MEs design and review board layouts
Onshore and offshore resources
Ongoing internship programs with leading universities to help scale our growth
Top 1% of industry in on time deliveries
3D modeling of components and PCB assembly
In House CAM team for DFX analysis
